MAG A750GL PCIE5

Front I/O Ports
VGA Card Support
CPU Cooler Support
Power Supply
WEIGHT (CARD)
Case Form Factor
Efficiency Rating
Modular
Dimensions
Fan Size
Fan Bearing
Dimensions (DxWxH)
Bearing Type
PFC Type
Rated Speed
Power Watt
Input Voltage Range
Power Excursion
Air Flow
Input Frequency Range
Static Air Pressure
Protection
ATX (24 pin)
Connector
Pre-installed Fan Type
Life Expectancy
EPS (4+4 pin)
PCI-E 5.0 (16 pin)
PCI-E (6+2 pin)
SATA (15 pin)
MOLEX (4 pin)
FDD (4 pin)

Front I/O Ports

2 x USB 3.0 + HD Audio / Mic

VGA Card Support

Max 400mm / 15.75 inch

CPU Cooler Support

Max 170mm / 6.69 inch

Power Supply

Standard ATX

WEIGHT (CARD)

169g

Case Form Factor

Mid-Tower

Efficiency Rating

80 PLUS Gold (up to 90%)

Modular

Yes (full modular)

Dimensions

120mm x 120mm x 25.6mm

Fan Size

120 mm

Fan Bearing

Fluid Dynamic Bearing

Dimensions (DxWxH)

140 x 150 x 86 mm

Bearing Type

Hydro-Dynamic Bearing

PFC Type

Active PFC

Rated Speed

500 - 1800 ±15% RPM

Power Watt

750W

Input Voltage Range

100~240 VAC

Power Excursion

1500W (*up to 200% of the PSU's rated power for 100μs)

Air Flow

19.79 - 71.27 CFM

Input Frequency Range

47-63Hz

Static Air Pressure

0.16 - 2.09 mm-H20

Protection

OCP / OVP / OPP / OTP / SCP / UVP

ATX (24 pin)

Connector

4-Pin PWM/DC

Pre-installed Fan Type

ARGB

Life Expectancy

MTTF 150,000 Hours (25℃)

EPS (4+4 pin)

PCI-E 5.0 (16 pin)

1 (450W)

PCI-E (6+2 pin)

SATA (15 pin)

MOLEX (4 pin)

FDD (4 pin)

Semua gambar dan deskripsi hanya sebagai ilustrasi saja. Spesifikasi poduk, fungsi, dan tampilan dapat berbeda bedasar CPU dan Chipset yang berbeda. Untuk spesifikasi yang lebih detil, silahkan periksa halaman spesifikasi produk.
